CC83 INDOOR
Straight-cut sliding system for exterior use with 82 mm frame on rails. 10 mm tempered laminated glazing. 5+5 laminated. Fittings with multipoint locking system. Sealing gaskets with wool pile to ensure quality closure.
Options:
- Flat lower frame option
- Additional lanes
- Blocking of intermediate sashes by means of lockable points.
- Side sash with multipoint lock compatible with different handle and knob designs
Technical specifications
Register here to access the document.
Catalog
Register here to access the document.
Classification of tests
Wind resistance
Resistance to wind loads
Class 5 (UNE-EN 1932:2014)
Opening options
Recommended dimensions
Benefits
This sliding glass system from Aluminios Galisur is designed for enclosing terraces, balconies, porches, and as a complement to pergolas and sliding roofs. This carpentry with non-continuous bearing profiles with respect to the lower guide guarantees rapid drainage of rainwater. Easy mounting and integration with the finished work. The “Sun Resistant” PVC vertical corner pieces allow maximum visibility and comfort. With multiple opening configurations and locking options.
